Figure 2.12
Terminating a Remote I/O Link Using the Module Mounted Resistor
ÉÉ
J4
J5
T1
J2
123
Blue
1
2
SH
Shield
Clear
123
123
Not Last Rack
(Factory Default)
Last Rack,
Termination
Resistor Inserted
Enables 150 ohm
Termination Resistor
Figure 2.13
Terminating a Remote I/O Link Using an External Resistor
To
Blue
Shield
Clear
Remote I/O Module
Another Remote I/O
Link Device
ÉÉ
1
2
I50 Ohm
or
82 Ohm
Enclosed
Remote I/O Module
Sh
1 watt,
± 10%
