Allen-Bradley 1203-GD1 Getting Started Manual

2–17Installation
Publication 1203–5.1 –– July, 1997
SMP 3
An Allen-Bradley SCANport cable is used to connect the
communications adapter and an SMP 3. See the cable requirements
on page 2–16 for details on cable length.
Figure 2.15
SCANport connection on Remote I/O
AB0538A
Enclosed
Adapter
SMP 3
RESET
Remote
Reset
SCANport
SMC Dialog Plus
An Allen-Bradley Bulletin 1202 SCANport cable is required to
connect the communications adapter and the SMC Dialog Plus
controller.
Figure 2.16
SCANport connection on Remote I/O
AB0537A
Allen-Bradley SMC Dialog Plus
ESC SEL
Enclosed
Adapter
SMC Dialog Plus
SCANport
