Chapter
5
Publication 1203–5.1 –– July, 1997
Specifications
Chapter 5 provides you with background information and
specifications that you may need to install, repair, or apply your
remote I/O communications module.
Table 5.A
General Indications
Open Style
(1336–GM1)
Enclosed Style –– 115V ac
(1203–GD1)
Enclosed Style –– 24V dc
(1203–GK1)
Environmental
Operating temperature
0–50°C (32–122°F)
0–50°C (32–122°F) 0–50°C (32–122°F)
Storage temperature
–40–85°C (–40–158°F)
–40–85°C (–40–158°F) –40–85°C (–40–158°F)
Relative humidity 0–95%, non–condensing 0–95%, non–condensing 0–95%, non–condensing
Electrical
Input voltage Supplied by drive 85–264V ac, 1 ph
24V dc, ±10%
Input frequency NA 45–63 Hz NA
Input current NA 35 mA maximum 0.4 amps maximum
SCANport load 60 mA 60 mA 60 mA
Communications
Drive side SCANport peripheral interface
PLC side Allen Bradley remote I/O
Baud rates 57.6K, 115.2K, or 230.4K
Rack size 1/4, 1/2, 3/4, or full
Dimensions
Enclosure type Open (IP00) NEMA 1 (IP30) NEMA 1 (IP30)
Package size Not applicable 45mm x 76mm (1.8 x 3.0 in) 45mm x 76mm (1.8 x 3.0 in)
