Allen-Bradley 1336 PLUS Troubleshoot Manual

Preface P–7
Publication 1336 IMPACT-6.2 – March 1998
Table P.D
Language Modules
Description
Option Code
English/English
English/French

English/German

English/Italian

English/Japanese

English/Spanish

EN
FR
DE
IT
JP
ES

Not available at time of printing.
Table P.E
Options
Code
Description

Code
Description

Human Interface Modules, NEMA Type 1 (IP20) Communication Options
HAB
HAP
HA1
HA2
Blank – No Functionality
Programmer Only
Programmer/Controller with Analog Pot
Programmer/Controller with Digital Pot
GM1
GM2
GM5
Single Point Remote I/O
RS-232/422/485, DF1, & DH485 Protocol
DeviceNet™
Human Interface Modules, NEMA Type 4/12 (IP65/54) L Option Boards
HJP
HJ2
Programmer Only
Programmer/Controller with Digital Pot
L4
L7E
L5
L8E
L6
L9E
Contact Closure
Contact Closure & Encoder Feedback
+24V AC/DC
+24V AC/DC & Encoder Feedback
115V AC
115V AC & Encoder Feedback

For a more functionally complete description of each option, refer to Publication 1336 IMPACT-1.0.

Allen-Bradley 1336 PLUS Specifications

General

Input Voltage	200-240VAC, 380-480VAC, 500-600VAC
Output Frequency	0-400 Hz
Frequency	50/60 Hz
Dimensions	Varies by model
Weight	Varies by model
Enclosure	NEMA 1
Output Current	Varies by model
Power Rating	Varies by model
Communication	RS-485
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Storage Temperature	-40 to 70°C (-40 to 158°F)
Humidity	5 to 95% non-condensing
Control Method	Sensorless Vector
