Allen-Bradley 1734-AENTR User Manual

Publication 1734-UM014A-EN-P - November 2010
34 Configure the Adapter for Direct Connection in RSLogix 5000 Software
3. Select your adapter from the list, and click OK, noting that we entered
these values on the General Tab of the New Module dialog.
.
The New Module dialog opens.
4. Click Change...
The Module Definition dialog opens.
Name POINT_IO_Adapter
IP Address 10.88.70.2
IMPORTANT
The Slot field appears grey because the slot is automatically 0 for
the 1734-AENTR adapter.
