Allen-Bradley 1734-AENTR User Manual

Publication 1734-UM014A-EN-P - November 2010
Configure the Adapter for Direct Connection in RSLogix 5000 Software 41
The Controller Tags dialog opens. You see the tags created for the
1734-AENTR adapter and its digital I/O modules.
2. Click the Edit Tags tab at the bottom of the Controller Tags dialog.
3. Create the following tag:
4. Close the Controller Tags dialog.
Tags created by the system
Enter the new tag here
Tag Type
Parts_Count Counter
