Publication 1734-UM014A-EN-P - November 2010
EtherNet/IP I/O Adapter Specifications 77
Specifications – POINT I/O 2 Port EtherNet/IP Adapter 1734-AENTR
Specification Description
Expansion I/O
capacity
1734-OE4C 75 mA
1734-IA4 75 mA
1734-IM4 75 mA
1734-OA4 75 mA
1734-IR2E 75 mA
1734-8CFG 100 mA
Ethernet
communication rate
10/100 Mbps, half or full-duplex
Module location Starter module - left side of the 1734 system
Dimensions (HxWxD),
approx.
76.2 x 73.0 x 133.4
(3.0 x 2.87 x 5.25)
Weight, approx. 280 g (9.87 oz)
Enclosure type rating Non (open style)
Terminal base screw
torque
0.8 Nm (7 in.-lb)
Conductors #22…#14 AWG (0.324...2.08)
solid or stranded wire rated at 75 °C or higher
Wire size 1.2 mm (3/4 in.) insulation, max
North American temp
code
T4
IEC temp code T4
