Allen-Bradley 1734-IE2C User Manual

POINT I/O 2 Current and 2 Voltage Input Analog Modules 7
Publication 1734-IN027C-EN-E - October 2016
POINT I/O Input Module with 1734-TOP or 1734-TOPS One-piece Terminal Base
Description Description
1 Module locking mechanism 6 1734-TB or 1734-TBS mounting base
2 Slide-in writable label 7 Interlocking side pieces
3 Insertable I/O module 8 Mechanical keying (orange)
4 Removable terminal block (RTB) handle 9 DIN rail locking screw (orange)
5 Removable terminal block with screw
(1734-RTB) or spring clamp (1734-RTBS)
10 Module wiring diagram
Description Description
1 Module locking mechanism 5 Interlocking side pieces
2 Slide-in writable label 6 Mechanical keying
3 Handle 7 DIN rail locking screw (orange)
4 1734-TOP or 1734-TOPS one-piece terminal
base with screw or spring clamp
8 Module wiring diagram
1
8
7
6
5
2
3
4
45712
