Allen-Bradley 1734-IE2C User Manual

6 POINT I/O 2 Current and 2 Voltage Input Analog Modules
Publication 1734-IN027C-EN-E - October 2016
Before You Begin
Read this manual for information about how to install the following modules.
• 1734-IE2C, Series C, POINT I/O Current Input Analog Module
• 1734-IE2V, Series C, POINT I/O Voltage Input Analog Module
You can use these Series C POINT I/O™ Input modules with DeviceNet and PROFIBUS
adapters. If you are using RSLogix 5000 software, version 11 or higher, you can also use the
modules with ControlNet and Ethernet adapters.
Use this diagram to identify the external features of the module.
POINT I/O Input Module with 1734-TB or 1734-TBS Base
Analog
Voltage
Output
Module
Status
Network
Status
NODE:
0
1
1
10
9
8
7
2
4
5
6
3
The wiring base assembly includes
terminal base, 1734-TB or 1734-TBS,
which consists of a mounting base,
1734-MB, and removable terminal block,
1734-RTB or 1734-RTBS.
43930

Allen-Bradley 1734-IE2C Specifications

General

Brand	Allen-Bradley
Model	1734-IE2C
Category	I/O Systems
Language	English
