190 Rockwell Automation Publication 1756-UM540E-EN-P - December 2017
Appendix A Analog I/O Module Tag Definitions
Ch[x].SensorType SINT Sensor type used on the channel. The Input Type
connected to the channel determine the sensor type.
If an RTD input type is connected to
the channel:
0 = Ω
1 = 100Ω PT 385
2 = 200Ω PT 385
3 = 500Ω PT 385
4 = 1000Ω PT 385
5 = 100Ω PT 3916
6 = 200Ω PT 3916
7 = 500Ω PT 3916
8 = 1000Ω PT 3916
9 = 10Ω CU 427
10 = 120Ω NI 672
11 = 100Ω NI 618
12 = 120Ω NI 618
13 = 200Ω NI 618
14 = 500Ω NI 618
If a Thermocouple input type is
connected to the channel:
0 = mV
1 = B
2 = C
3 = E
4 = J
5 = K
6 = N
7 = R
8 = S
9 = T
10 = TXK/XK(L)
11 = D
Ch[x].NotchFilter SINT Notch Filter removes line noise for the channel.
There is a relationship between this setting and the RPI
setting. For more information on Notch Filter, see page 61
.
0 = 10 Hz
1 = 50 Hz
2 = 60 Hz
3 = 100 Hz
5 = 1000 Hz
6 = 20 Hz
7 = 15 Hz
8 = 500 Hz
9 = 5000 Hz
10 = 5 Hz
Ch[x].AlarmDisable BOOL Disables all alarms on the module. 0 = Enabled
1 = Disabled (default)
Ch[x].ProcessAlarmLatch BOOL Latches Process alarms.
If this tag is set to latch the process alarms, the
I:Ch[x].LLAlarm, I:Ch[x].LAlarm, I:Ch[x].HAlarm or
I:Ch[x].HHAlarm tags do not clear until explicitly
unlatched.
0 = Latching disabled (default)
1 = Latching enabled
Ch[x].RateAlarmLatch BOOL Latches the Ramp alarm.
If this tag is set to latch the ramp alarm, the
I:Ch[x].RampAlarm tag does not clear until explicitly
unlatched.
0 = Latching disabled (default)
1 = Latching enabled
Ch[x].Disable BOOL Disables the channel. 0 = Enabled (default)
1 = Disabled
Table 31 - 1756-IRT8I Module - Configuration Tags (continued)
Tag Name Data Type Definition Valid Values
