Allen-Bradley 1762-OF4 - Output Specifications; Electrical and Performance Attributes

18 Analog Output Module
Publication 1762-IN016D-EN-P - June 2013
Specifications
Output
Attribute Value
Number of outputs 4 single-ended (unipolar)
D/A converter type R-2R Ladder Voltage Switching
Module update time 2.5 ms
Resistive load on current output 0…500 Ω (includes wire resistance)
Load range on voltage output > 1KΩ
Reactive load, current output < 0.1 mH
Reactive load, voltage output < 1 μF
Typical overall accuracy
(1)
(1)
Includes offset, gain, non-linearity and repeatability error terms.
±1.17% full scale @ -20…65 °C (-4…149 °F)
±0.5% full scale @ 25 °C (77 °F)
Output ripple
range 0…500 Hz
(referred to output range)
< ±0.1%
Non-linearity (in percent full scale) < ±0.59%
Open and short-circuit protection Continuous
Output protection ±32 mA
