34 Rockwell Automation Publication IASIMP-QS024C-EN-P - August 2014
Chapter 2 Prepare the Computer and Load Controller Firmware
The Add New RSLinx Driver dialog box
appears.
4. Click OK to keep the default name.
A Configure driver:AB_ETHxxx dialog
box appears. The full name of the dialog box
varies by what driver type was chosen in step
3.
This example uses the EtherNet/IP Driver; the driver name is AB_ETHIP-1.
5. Select an Ethernet card and click OK.
This new driver is available.
6. Verify that the driver’s Status is Running and
click Close.
