Where to Start
Sample Panel Layout
The sample panel layout shows the orientation of an example CompactLogix 5370 L1 control system using an EtherNet/IP
network.
IMPORTANT
The following graphic is an example panel layout. The layout of CompactLogix 5370 L1 control systems varies by application.
AC Line Filter
PowerFlex 70 Drive Kinetix 350 Drive
Line Interface Module
CompactLogix 5370 L1
Control System
Ethernet Switch
Distributed POINT I/O Modules
Through-the-door
Disconnect
PanelView Plus Terminal
E-stop Push Button
PowerFlex 40 Drive
