20 Rockwell Automation Publication IASIMP-QS023B-EN-P - December 2012
Chapter 1 Prepare the CompactLogix 5370 L3 Controller Hardware
Install the Networks
Before you install your CompactLogix 5370 L3 control hardware, you must install the network
on which it will operate, that is, an EtherNet/IP or DeviceNet network.
We recommend that you install both networks.
For more information on installing either of these networks, see the publications listed in the
following table.
The publications listed previously describe how to install the communication network and not
how to connect your controller to the network. Make Network Connections
on page 26
describes how to connect your controller to the networks.
Network Publication Title Publication Number
EtherNet/IP EtherNet/IP Media Planning and Installation Manual NA - Click here to access the publication
Stratix 6000 Ethernet Managed Switches Installation Instructions 1783-IN004
Stratix 6000 Ethernet Managed Switch User Manual 1783-UM001
DeviceNet DeviceNet Media Design and Installation Guide DNET-UM072
