Specifications
A–4
Publication
17946.5.2 - May 1996
Specifications
- 1794OE4/B Analog Output Module
General Specifications
External dc Power Supply Voltage
Voltage Range
Supply Current
24V dc nominal
19.2 to 31.2V dc (includes 5% ac ripple)
70mA @ 24V dc (not including outputs)
Dimensions Inches
(Millimeters)
1.8H x 3.7W x 2.1D
(45.7 x 94.0 x 53.3)
Environmental Conditions
Operational Temperature
Storage Temperature
Relative Humidity
Shock Operating
Nonoperating
Vibration
0 to 55
o
C (32 to 131
o
F)
-40 to 85
o
C (-40 to 185
o
F)
5 to 95% noncondensing (operating)
5 to 80% noncondensing (nonoperating)
30 g peak acceleration, 11(+
1)ms pulse width
50 g peak acceleration, 11(+
1)ms pulse width
Tested 5 g @ 10-500Hz per IEC 6826
Conductors Wire Size
Category
12 gauge (4mm
2
) stranded maximum
3/64 inch (1.2mm) insulation maximum
2
2
Agency Certification
(when product or packaging is marked)
• CSA certified
• CSA Class I, Division 2, Groups A, B, C, D certified
• UL listed
• CE marked for all applicable directives
Installation Instruction Publication 17945.5
1
Includes
of
fset, gain, nonlinearity and repeatability error terms.
2
Use this conductor category information for planning conductor routing as described in publication 17704.1, Wiring and
Grounding Guidelines for Noise Immunity
."
