Allen-Bradley 1794-IE4XOE2 Series B User Manual

P–2 Using This Manual
Publication 17946.5.2 - May 1996
We use these conventions in this manual:
In this manual, we show: Like this:
that there is more information about a topic
in another chapter in this manual
that there is more information about the
topic in another manual
More
For additional information on FLEX I/O systems and modules, refer
to the following documents:
Catalog
Publications
Catalog
Number
Voltage Description
Installation
Instructions
User
Manual
1794 1794 FLEX I/O Product Data
17942.1
1794ACN 24V dc ControlNet Adapter
17945.8
1794ADN 24V dc DeviceNet Adapter 17945.14 17946.5.5
1794ASB 24V dc Remote I/O Adapter 17945.11 17946.5.3
1794TB2
1794TB3
2wire Terminal Base
3wire Terminal Base
17945.2
1794TBN Terminal Base Unit
17945.16
1794TBNF Fused Terminal Base Unit
17945.17
1794TB3T Temperature Terminal Base Unit
17945.41
1794IB16 24V dc 16 Input Module
17945.4
1794OB16 24V dc 16 Output Module
17945.3
1794IB10XOB6 24V dc 10 Input/6 Output Module
17945.24
1794IE8 24V dc Selectable Analog 8 Input Module
17945.6
1794OE4 24V dc Selectable Analog 4 Output Module
17945.5
17946.5.2
1794IE4XOE2 24V dc 4 Input/2 Output Analog Module
17945.15
1794IR8 24V dc 8 RTD Input Analog Module 17945.22 17946.5.4
1794IT8 24V dc 8 Thermocouple Input Module 17945.21 17946.5.7
1794IB8S 24V dc Sensor Input Module
17945.7
1794IA8 120V ac 8 Input Module
17945.9
1794OA8 120V ac Output Module
17945.10
1794CE1 Extender Cable
17942.12
1794NM1 Mounting Kit
17942.13
1794PS1 24V dc Power Supply
17945.35
Conventions
For Additional Information
