Rockwell Automation Publication 2080-UM004C-EN-E - March 2015 67
Specifications Appendix A
Specifications – 2080-TRIMPOT6
Attribute Value
Data range 0…255
Number of trimpot 6
Temperature, operating IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-20...65 °C (-4…149 °F)
Temperature, nonoperating IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal
Shock):
-40...85 °C (-40…185 °F)
Temperature, surrounding air, max 65 °C (149 °F)
Relative humidity IEC 60068-2-30 (Test Db, Unpackaged Damp Heat):
5%...95% non-condensing
Altitude, operating 2000 m
Certifications – 2080-TRIMPOT6
Certification (when
product is marked)
(1)
(1) See the Product Certification link at http://www.rockwellautomation.com/products/certification/ for
Declarations of Conformity, Certificates, and other certification details.
Value
c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada.
See UL File E322657.
UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations,
certified for U.S. and Canada. See UL File E334470.
CE European Union 2004/108/EC EMC Directive, compliant with:
EN 61326-1; Meas./Control/Lab., Industrial Requirements
EN 61000-6-2; Industrial Immunity
EN 61000-6-4; Industrial Emissions
EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
C-Tick Australian Radiocommunications Act, compliant with:
AS/NZS CISPR 11; Industrial Emissions
General and Environmental Specifications – 2080-TC2, 2080-RTD2
Attribute 2080-RTD2 2080-TC2
Mounting torque 0.2 Nm (1.48 lb-in.)
Terminal screw torque 0.22…0.25 Nm (1.95…2.21 lb-in.)
using a 2.5 mm (0.10 in.) flat-blade screwdriver
Wire size 0.14…1.5 mm
2
(26…16 AWG) solid copper wire or
0.14…1.0 mm
2
(26…17 AWG) stranded copper wire
rated @ 90 °C (194 °F ) insulation max
Input impedance > 5 MΩ > 300 KΩ
Common mode rejection ratio 100 dB 50/60Hz
Normal mode rejection ratio 70 dB @ 50/60 Hz
Resolution 14-bit
