114 Rockwell Automation Publication 5069-UM004A-EN-P - April 2019
Chapter 4 Output Module Features
Table 27 describes what happens when a No Load condition is corrected.
You can monitor a module tag in your program that corresponds to the No
Load Detection to check for a fault. For more information on the tag, see
Appendix B,
Module Tag Definitions on page 231.
You can also monitor a point for the presence of a No Load condition via the
diagnostics that are available in the Module Properties dialog box in
Logix Designer application.
For more information on where to configure No Load Detection, see
the following:
• 5069-OB8 -
page 183
• 5069-OB16 and 5069-OB16K module -
page 184
• 5069-OB16F module -
page 185
As noted on
page 113, you cannot configure No Load Detection on Compact
5000 I/O safety modules. It is on by default.
Table 27 - No Load Detection - Compact 5000 I/O Digital Output Modules
Tag Value I/O Status Indicator State
I.Ptxx.NoLoad tag = 0 • Off if the output is off.
• Steady yellow if the output is on.
