POINT I/O Input Module 19
Publication 1734-IN051D-EN-P - April 2004
Shock
Operating
Non-operating
IEC 60068-2-27 (Test Ea, Unpackaged Shock)
30g peak acceleration
50g peak acceleration
Vibration IEC 60068-2-6, (Test Fc, Operating)
Tested 5g @ 10-500Hz
ESD Immunity IEC 61000-4-2:
6kV contact discharges
8kV air discharges
Radiated RF Immunity IEC 61000-4-3:
10V/m with 200Hz 50% Pulse 100%AM at 1890Mhz
10V/m with 200Hz 50% Pulse 100%AM at 900Mhz
10V/m with 1kHz sine-wave 80%AM from 30MHz to
2000MHz
EFT/B Immunity IEC 61000-4-4:
±4kV at 2.5kHz on signal ports
±4kV at 2.5kHz on power ports
Surge Transient Immunity IEC 61000-4-5:
±1kV line-line(DM) and ±2kV line-earth(CM) on power
and signal ports
Conducted RF Immunity IEC 61000-4-6:
10Vrms with 1kHz sine-wave 80%AM from 150kHz to
80MHz
Emissions CISPR 11
Group 1, Class A
Enclosure Type Rating None (open-style)
Conductors Wire Size
Category
14 AWG (2.5mm
2
) - 22 AWG (0.25mm
2
) solid or stranded
copper wire rated at 75°C or greater
3/64 inch (1.2mm) insulation maximum
2
2
Terminal Base Screw Torque 7 pound-inches (0.8Nm)
Mass 1734-IB2 - 1.09 oz/30.9 grams
1734-IB4 - 1.12 oz/31.8 grams
1734-IB8 - 1.14 oz/32.3 grams
