Allen-Bradley C Series User Manual

Publication 1734-IN051D-EN-P - April 2004 PN 957859-41
Supersedes publication 1734-IN051C-EN-P - April 2002 © (2004) Rockwell Automation, Inc. Printed in USA
Field Wiring Terminations 1734-IB2
0 - Input 0 1 - Input 1
2 - No Connection 3 - No Connection
4 - Common 5 - Common
6 - User Supply 7 - User Supply
1734-IB4
0 - Input 0 1 - Input 1
2 - Input 2 3 - Input 3
4 - Common 5 - Common
6 - User Supply 7 - User Supply
1734-IB8
0 - Input 0 1 - Input 1
2 - Input 2 3 - Input 3
4 - Input 4 5 - Input 5
6 - Input 6 7 - Input 7
Certifications (when product
is marked)
C-UL-US - UL Listed Industrial Control Equipment,
certified for US and Canada
C-UL-US - UL Listed for Class I, Division 2, Groups A,
B, C and D Hazardous locations, certified
for US and Canada
EEx
3
European Union 94/9/EEC ATEX Directive,
compliant with:
EN 50021; Potentially Explosive Atmospheres,
Protection “n” (Zone 2)
CE
3
- European Union 89/336/EEC EMC Directive,
compliant with:
EN 61000-6-4; Industrial Emissions
EN 50082-2; Industrial Immunity
EN 61326; Meas./Control/Lab., Industrial
Requirements
EN 61000-6-2; Industrial Immunity
C-Tick
3
- Australian Radiocommunications Act
compliant with AS/NZS CISPR 11, Industrial
Emissions
1 Input off-to-on filter time is the time from a valid input signal to recognition by the module. Input on-to-off
time is the time from a valid input signal to recognition by the module.
2 Use this conductor category information for planning conductor routing as described in publication
1770-4.1, “Industrial Automation Wiring and Grounding Guidelines.”
3 See the Product Certification link at www.ab.com for Declaration of Conformity, Certificates, and
other certification details.
