Allen-Bradley CompactLogix 5370 L1 Quick Start

Rockwell Automation Publication IASIMP-QS024C-EN-P - August 2014 13
Preface
Parts List
Tabl e 3 lists the hardware that is used in this quick start. Hardware requirements are listed at the beginning of each chapter.
Additional Resources
These documents contain additional information concerning related products from Rockwell Automation.
Table 3 - Parts Used with This Quick Start
Quantity Cat. No. Description
1 or more N/A DIN rail (steel, not aluminum)
1 One of the following:
• 1769-L16ER-BB1B
• 1769-L18ER-BB1B
• 1769-L18ERM-BB1B
CompactLogix 5370 L1 controller
The tasks that are described in this publication use a 1769-L18ERM-BB1B controller.
1 User Selected, for example1606-XLE120E Switched-mode power supply
1 1734-OB4E POINT I/O 8-point 24V DC electronically fused output module
1 1783-EMS08T Stratix 6000 Ethernet managed switch
2
(1)
1585J-M8PBJM-2 RJ45-to-RJ45 patchcord Ethernet cables
(1) One Ethernet cable is required to connect the controller to the Ethernet switch and a second Ethernet cable is required to connect the Ethernet switch to the computer.
Table 4 - Additional Resources
Resource Description
CompactLogix 5370 Controllers User Manual, publication 1769-
UM021
Describes how to design, install, operate, and troubleshoot a CompactLogix 5370 control system.
ControlFLASH Firmware Upgrade Software User Manual,
publication 1756-UM105
Provides details regarding the installation of ControlFLASH software and execution of firmware upgrades.
Ethernet Design Considerations Reference Manual, publication
ENET-RM002
Describes installing an EtherNet/IP network.
EtherNet/IP Embedded Switch Technology Application Guide,
publication ENET-AP005
Describes using the controller in a DLR network topology.
EtherNet/IP Network Configuration User Manual, publication
ENET-UM001
Describes how to install, configure, and operate EtherNet/IP modules.
Integrated Architecture and CIP Syne Configuration Application
Technique, publication IA-AT003
Describes using the controller in an application that includes Integrated Motion on the EtherNet/IP network.
Integrated Motion on the EtherNet/IP Network Configuration
and Startup User Manual, publication MOTION-UM003
Describes using the controller in an application that includes Integrated Motion on the EtherNet/IP network.
Logix5000 Control Systems: Connect POINT I/O Modules over
an EtherNet/IP Network Quick Start, publication IASIMP-QS027
Describes basic steps that are required to include distributed POINT I/O modules over an EtherNet/IP network in a
Logix5000 control system, including hardware, firmware, and software considerations.
Logix5000 Control Systems: Connect PowerFlex 40 Drives over
an EtherNet/IP Network Quick Start, publication IASIMP-QS029
Describes basic steps that are required to include PowerFlex 40 drives over an EtherNet/IP network in a Logix5000
control system, including hardware, firmware, and software considerations.
Logix5000 Control Systems: Connect PowerFlex 70 Drives over
an EtherNet/IP Network Quick Start, publication IASIMP-QS031
Describes basic steps that are required to include PowerFlex 70 drives over an EtherNet/IP network in a Logix5000
control system, including hardware, firmware, and software considerations.
Logix5000 Control Systems: Connect Kinetix 350 Drives over an
EtherNet/IP Network Quick Start, publication IASIMP-QS032
Describes basic steps that are required to include Kinetix 350 Multi-axis Servo drives over an EtherNet/IP network in
a Logix5000 control system, including hardware, firmware, and software considerations.
Logix5000 Control Systems: Connect a PanelView Plus Terminal
over an EtherNet/IP Network Quick Start, publication IASIMP-
QS033
Describes basic steps that are required to include PanelView Plus terminals over an EtherNet/IP network in a
Logix5000 control system, including hardware, firmware, and software considerations.
