Allen-Bradley CompactLogix 5370 L1 Quick Start

48 Rockwell Automation Publication IASIMP-QS024C-EN-P - August 2014
Chapter 4 Create a Logix Designer Project
Before You Begin
Before you begin, complete these tasks:
• The tasks that are described in Chapter 1, Prepare the CompactLogix 5370 L1 Controller Hardware
on page 15,
including the following:
– Install the EtherNet/IP network.
– Install the controller and the local expansion module.
– Wire power to the controller.
– Make network connections.
• The tasks that are described in Chapter 2, Prepare the Computer and Load Controller Firmware
on page 29,
including the following:
– Install the Studio 5000 environment and RSLinx Classic software.
Logix Designer application is installed when you install the Studio 5000 environment.
– Configure an EtherNet/IP driver in RSLinx Classic software.
– Set the IP address for the computer.
– Load firmware on the controller.
• Set the IP address for the controller as described in Chapter 3 on page 43
.
• Verify that all devices are powered.
What You Need
You need Logix Designer application to complete the tasks in this chapter.
