Rockwell Automation Publication 1756-RM100F-EN-P - October 2018 151
Diagnostics and Status Indicators with CompactLogix Systems Chapter 8
UPDT A firmware update is being conducted from the SD card upon powerup.
If you do not want the firmware to update upon powerup, change the Load Image property of the controller.
Rev XX.xxx The firmware major and minor revision of the controller.
5069-L3xxx The controller catalog number and series.
Link Ax Down Message appears when an Ethernet port does not have a network connection. Message scrolls continuously during operation.
IMPORTANT: When the controller operates in Dual-IP mode, this information is provided for each link, that is, Link A1 and Link A2. The
link name appears before the information.
Link Ax Disabled Message appears when you have disabled an Ethernet port. Message scrolls continuously during operation.
IMPORTANT: When the controller operates in Dual-IP mode, this information is provided for each link, that is, Link A1 and Link A2. The
link name appears before the information.
DHCP- 00:00:XX:XX:XX:XX Message appears when the controller is set for DHCP, but not configured on a network. The message shows the MAC address of the
controller. Message scrolls continuously during operation if no IP address is set.
IMPORTANT: When the controller operates in Dual-IP mode, this information is provided for each port, that is, Port A1 and Port A2.
The port name appears before the information.
Ethernet Port Rate/Duplex State The current port rate and duplex state when an Ethernet port has a connection. Message scrolls continuously during operation.
IMPORTANT: When the controller operates in Dual-IP mode, this information is provided for each link, that is, Link A1 and Link A2. The
link name appears before the information.
IP Address The IP address of the controller. Appears on powerup and scrolls continuously during operation. If the IP address is not yet set, the MAC
address appears.
IMPORTANT: When the controller operates in Dual-IP mode, this information is provided for each port, that is, Port A1 and Port A2.
The port name appears before the information.
Duplicate IP - 00:00:XX:XX:XX:XX Message appears when the controller detects a device with the same IP Address on the network. The message shows the MAC address
of the device with the duplicate IP Address. Message scrolls continuously during operation.
IMPORTANT: When the controller operates in Dual-IP mode, this information is provided for each port, that is, Port A1 and Port A2.
The port name appears before the information.
DHCP-Address Lost The controller has communicated with the DHCP server to renew the IP address. The server either did not reply or did not renew the IP
address.
The controller continues to operate, but with no Ethernet connectivity out of this port.
IMPORTANT: When the controller operates in Dual-IP mode, this information is provided for each port, that is, Port A1 and Port A2.
The port name appears before the information.
IP Address/Mask/Gateway/DNS Invalid The DHCP server responded with an unusable combination.
IMPORTANT: When the controller operates in Dual-IP mode, this information is provided for each port, that is, Port A1 and Port A2.
The port name appears before the information.
IP Address Invalid The IP address that is used in the port configuration is not valid.
IMPORTANT: When the controller operates in Dual-IP mode, this information is provided for each port, that is, Port A1 and Port A2.
The port name appears before the information.
Mask Invalid The Subnet/Network Mask used in the port configuration is not valid.
IMPORTANT: When the controller operates in Dual-IP mode, this information is provided for each port, that is, Port A1 and Port A2.
The port name appears before the information.
Gateway Invalid The Gateway address that is used in the port IP configuration is not valid.
IMPORTANT: When the controller operates in Dual-IP mode, this information is provided for each port, that is, Port A1 and Port A2.
The port name appears before the information.
Table 21 - General Status Messages (continued)
Message Interpretation
