Replacement Considerations with CompactLogix and Compact GuardLogix Systems Chapter 3
Controller Properties
This table lists Controller Properties dialog box tabs and indicates how a tab is
different on a CompactLogix 5380 controller compared to a
CompactLogix 5370 L3 controller.
Controller
Properties Tab
Comments
General Same functionality as the 5370 controllers.
Major Faults Same functionality as the 5370 controllers.
Minor Faults Same functionality as the 5370 controllers.
Date/Time Same functionality as the 5370 controllers.
Advanced New parameter to enable Minor Overflow fault reporting. The System Overhead Time
Slice parameter was removed.
For more information, see page 62
.
SFC Execution Same functionality as the 5370 controllers.
Project Option to download custom properties when you download project documentation and
extended properties.
For more information, see page 63
.
Nonvolatile Memory Same functionality as the 5370 controllers.
Memory (Logix
Designer application,
version 28)
Capacity (Logix
Designer application,
version 29 and later)
The tabs indicate the same information but are named differently between the Logix
Designer application versions.
Indicates data usage. Data usage is indicated with one value that combines Data and
Logic memory usage and I/O memory usage.
See Memory Tab on page 64 or Capacity Tab on page 65.
Internet Protocol Same functionality as the 5370 controllers.
Port Configuration Same functionality as the 5370 controllers.
Network Same functionality as the 5370 controllers.
Security Now has additional security parameters.
For more information, see page 66
.
Alarm Log Not available for 5380 controllers in version 28.
Available in version 29 or later with the same functionality as the 5370 controllers.
