Chapter 2 Replacement Considerations with ControlLogix 5580 and GuardLogix 5580 Systems
Advanced Tab
The Advanced tab provides a way to assign the Controller Fault Handler and
Power-up Handler. You can also match a project to a specific controller by
serial number.
• Report Overflow Faults is a new parameter that lets you control Minor
Overflow fault reporting. When you create a project, the default setting
is disabled. When you import or open a legacy project, the default
setting is enabled. For more information, see Minor Fault on Overflow
on page 128.
• System Overhead Time Slice is no longer required for 5580 controllers,
and the parameter is removed.
Figure 1 - Controller Properties Dialog Box - Advanced Tab
5570 Controllers Example 5580 Controllers Example
Report Overflow Faults is enabled by default when
morphing a legacy project, but defaults to disabled
when creating a ControlLogix 5580 project.
