Allen-Bradley ControlLogix 1756-IF8 User Manual

10 ControlLogix Voltage/Current Input Module
Publication 1756-IN040C-EN-P - October 2000
1. All terminals marked RTN are connected internally.
2. Terminals marked iRTN are not used for single-ended voltage wiring.
3. If separate power sources are used, do not exceed the specified isolation voltage.
40915-M
12
34
56
78
910
1112
1314
1516
1718
1920
2122
2324
2526
2728
2930
3132
3334
3536
+
–
+
–
IN-0
IN-1
IN-2
IN-3
IN-7
RTN
IN-4
IN-5
IN-6
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
i RTN-0
i RTN-1
i RTN-2
i RTN-3
i RTN-7
RTN
i RTN-4
i RTN-5
i RTN-6
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Shield ground
Channel 0
Channel 1
Shield ground
1756-IF8 Single-ended voltage wiring example
NOTES:
