Allen-Bradley FLEX I/O ControlNet D Series User Manual

FLEX I/O ControlNet Adapter Modules 5
Publication 1794-IN128E-EN-P - March 2011
Wire size Power connections:
Single wire connection: 0.33... 2.5 mm
2
(22...12
AWG) solid or stranded copper wire rated at 75 °C
(167 °F ) or greater 1.2 mm (3/64 in.) insulation max
Double wire connection: 0.33... 1.3 mm
2
(22...16
AWG) solid or stranded (not intermixed) copper wire
rated at 75 °C (167 °F ) or greater 1.2 mm (3/64 in.)
insulation max
Wiring Category
(1)
3 – on power ports
2 – on communications ports
North American temp code T4A
IEC temp code T4
Enclosure Type Rating None (open-style)
ControlNet Cable Belden RG-6/U
Weight 220 g (7.76 oz)
Dimensions
HxWxD
87.4 x 94 x 92 mm
(3.44 x 3.7 x 3.6 in.)
(1)
Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation
Wiring and Grounding Guidelines, publication
1770-4.1.
Environmental
Attribute Value
Temperature,
operating
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-25…55 °C (-13…131 °F)
-25 …70 °C (-13…158 °F) – 1794-ACNR15XT
Temperature,
surrounding air, max
55 °C (131 °F)
70 °C (158 °F) – 1794-ACNR15XT
Temperature,
nonoperating
IEC 60068-2-1 (Test Ab, Un-packaged Non-operating Cold),
IEC 60068-2-2 (Test Bb, Un-packaged Non-operating Dry Heat),
IEC 60068-2-14 (Test Na, Un-packaged Non-operating Thermal
Shock):
-40…85 °C (-40…185 °F)
Relative humidity IEC 60068-2-30 (Test Db, Unpackaged Damp Heat):
5 …95% non-condensing
Vibration IEC60068-2-6 (Test Fc, Operating):
5 g @ 10…500 Hz
Shock, operating IEC 60068-2-27 (Test Ea, Unpackaged Shock):
30 g
Shock, nonoperating IEC 60068-2-27 (Test Ea, Unpackaged Shock):
50 g
Emissions CISPR 11:
Group 1, Class A
ESD immunity IEC 61000-4-2:
6 kV contact discharges
8 kV air discharges
Radiated RF
immunity
IEC 61000-4-3:
10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz
10V/m with 200 Hz 50% Pulse 100% AM at 900 MHz
10V/m with 200 Hz 50% Pulse 100% AM at 1890 MHz
3V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz
EFT/B immunity IEC 61000-4-4:
±2 kV at 5 kHz on power ports
±2 kV at 5 kHz on communications ports
Surge transient
immunity
IEC 61000-4-5:
±2 kV line-earth(CM) on communications ports
Conducted RF
immunity
IEC 61000-4-6:
10V rms with 1 kHz sine-wave 80% AM from 150 kHz…80 MHz
Certifications (when product is marked)
(1)
Attribute Value
c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada.
See UL File E65584.
UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations,
certified for U.S. and Canada. See UL File E194810.
CE European Union 2004/108/EC EMC Directive, compliant with:
EN 61326-1; Meas./Control/Lab., Industrial Requirements
EN 61000-6-2; Industrial Immunity
EN 61000-6-4; Industrial Emissions
EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
C-Tick Australian Radiocommunications Act, compliant with:
AS/NZS CISPR 11; Industrial Emissions
General
Ex European Union 94/9/EC ATEX Directive, compliant with:
EN 60079-15; Potentially Explosive Atmospheres, Protection "n"
EN 60079-0; General Requirements
II 3 G Ex nA IIC T4 X
TÜV TÜV Certified for Functional Safety:
Capable of SIL 2
CI ControlNet Int'l conformance tested to ControlNet specifications
(1)
See the Product Certification link at http://www.ab.com for Declaration of Conformity, Certificates,
and other certification details.
Certifications (when product is marked)
(1)
