Module Configuration Attributes
Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018 481
This attribute represents the external DC Bus capacitance when the associated
drive is acting as a Common Bus Leader, supplying DC Bus power to one or more
Common Bus Followers. This attribute is not applicable when the Bus Regulator
Action is set to Common Bus Follower. The attribute is applicable when the Bus
Regulator Action is set to Disable or Shunt Regulator.
External Shunt Resistance
Usage Access T Data Type Default Min Max Semantics of Values
Optional - BD Set
REAL 0 0
Ohms
This attribute represents the resistance of the External Shunt Regulator resistor.
Bus Sharing Group
Usage Access T Data Type Default Min Max Semantics of Values
Optional - BD Set
USINT 0 - - Enumeration:
0 = Standalone
1 = Bus Group 1
2 = Bus Group 2
3 = Bus Group 3
4 = Bus Group 4
5 = Bus Group 5
6 = Bus Group 6
7 = Bus Group 7
8 = Bus Group 8
9 = Bus Group 9
10 = Bus Group 10
11 = Bus Group 11
12 = Bus Group 12
13 = Bus Group 13
14 = Bus Group 14
15 = Bus Group 15
16 = Bus Group 16
17 = Bus Group 17
18 = Bus Group 18
19 = Bus Group 19
20 = Bus Group 20
21 = Bus Group 21
22 = Bus Group 22
23 = Bus Group 23
24 = Bus Group 24
25 = Bus Group 25
This enumerated selection indicates the Bus Sharing Group the drive is assigned
to. Physically, a Bus Sharing Group represents a collection of drives that are wired
