Allen-Bradley Micro820 User Manual

Rockwell Automation Publication 2080-UM005B-EN-E - March 2015 37
Wire Your Controller Chapter 4
Digital Input
Controller Terminal
Number
Input Common
Terminal Label
Terminal
Number
Input Terminal
Label
2080-LC20-20QWB,
2080-LC20-20QWBR
2 “-DC24” (24V DC sink only) 3 I-00
4I-01
5I-02
6I-03
7 CM0 (24V DC sink/source) 8 I-04
9I-05
10 I-06
11 I-07
12 I-08
13 I-09
14 I-10
15 I-11
Digital Output
Controller Terminal
Number
Input Common
Terminal Label
Terminal
Number
Input Terminal
Label
2080-LC20-20QWB,
2080-LC20-20QWBR
6 CM0 (VAC/DC) 7 O-00
8 CM1 (VAC/DC) 9 O-01
10 CM2 (VAC/DC) 11, 12 O-02, O-03
13 CM3 (VAC/DC) 14, 15, 16 O-04, O-05, O-06

Allen-Bradley Micro820 Specifications

General

Processor	32-bit
Power Supply	24V DC
Programming Software	Connected Components Workbench
Series	Micro800
Mounting	DIN Rail
Memory	Embedded
Expansion	Yes
Controller Type	Programmable Logic Controller (PLC)
Communication	Ethernet/IP
Programming Language	Ladder Diagram, Function Block Diagram, Structured Text
I/O	Embedded
