MicroLogix 1000 Programmable Controllers User Manual
A–8
Response Times for dc Inputs 4 and Above (applies to 1761-L10BWA, 1761-L16BWA,
-L20BWA-5A, -L32BWA, -L10BWB, -L16BWB, -L20BWB-5A, -L32BWB, -L16BBB, and
-L32BBB controllers)
Nominal Filter
Setting (ms)
Maximum ON
Delay (ms)
Maximum OFF
Delay (ms)
0.50 0.500 0.500
1.00 1.00 1.000
2.00 2.000 2.000
4.00 4.000 4.000
8.00
➀
8.000 8.000
16.00 16.000 16.000
➀
This is the default setting.
Response Times for ac Inputs (applies to 1761-L16AWA, -L20AWA-5A, -L32AWA, and
-L32AAA controllers)
Nominal Filter
Setting (ms)
➀
Maximum ON
Delay (ms)
Maximum OFF
Delay (ms)
8.0 20.0 20.0
➀
There is only one filter setting available for the ac inputs. If you make another selection the
controller changes it to the ac setting and sets the input filter modified bit (S:5/13).
efesotomasyon.com - Allen Bradley,Rockwell,plc,servo,drive

Allen-Bradley MicroLogix 1000 Specifications

General

Communication Ports	RS-232
Power Supply	24V DC or 120/240V AC
Programming Software	RSLogix 500
Manufacturer	Allen-Bradley
Category	Controller
Series	MicroLogix
Programming Language	Ladder Logic
Input Voltage	24V DC or 120/240V AC
I/O Points	10 to 32 points
Processor Type	8-bit
Operating Temperature	0…55 °C (32…131 °F)
Processor	8-bit
