Preface
MicroLogix 1000 Programmable Controllers User Manual
D–20
Typical 3-Node Network
3-Node
Network
(not expandable)
1761-CBL-AS09
or
1761-CBL-AS03
1747-CP3
or 1761-CBL-AC00
APS
PanelView
550
PC
RJ45 port
1761-CBL-AM00
or
1761-CBL-
HM02
MicroLogix 1000
(Series C or later discrete or all analog)
24V dc
(Not needed in this
configuration since the
MicroLogix 1000 provides
power to the AIC+ via port 2.)
Selection Switch Up
AIC+
(1761-NET-AIC)
DB-9
RS-232 port
mini-DIN 8 RS-232 port
DH-485/DF1 port
