Hardware

Connecting the System

3–7

Connecting the Communication Cable to the DH-485 Connector

Note A

daisy-chained network is r

ecommended. W

e do

not

ecommend the following:

Connector

Belden

#3106A

#9842

Belden

#3106A or

#9842

Belden

#3106A or

#9842

Incorrect

Single Cable Connection

6 Termination

Common

2 Shield

Chassis Ground

White with Orange Stripes

Orange with White Stripes

Blue (#3106A) or

Blue with White Stripes (#9842)

Drain Wire

Shrink Tubing

Recommended

Multiple Cable Connection

to Successive Device

to Previous Device
