PanelView 800 HMI Terminals 17
Publication 2711R-IN001A-EN-P - January 2015
Connect Power
All PanelView 800 terminals connect to a 24V DC power source. The table shows the power ratings for each
device.
The internal, nonisolated power supply is protected against reverse polarity of the DC+ and DC-
connections.
The input power terminal block supports these wire sizes.
Power Ratings
Catalog No. Input Voltage Range Power Consumption, Max
2711R-T4T 18…32V DC (24V DC nom) 9 W (0.39 A)
2711R-T7T 11 W (0.40 A)
2711R-T10T 14 W (0.48 A)
ATTENTION: Connecting DC+ or DC- source to the functional earth terminal may damage the
device. Miswiring the DC+ source to the DC- input while connected to other equipment through
nonisolated ports may cause a ground loop current and damage the device.
WARNING: Use supply wires suitable for 30 °C (86 °F) above surrounding ambient.
WARNING: If you connect or disconnect wiring while the power is on, an electrical arc can
occur. This could cause an explosion in hazardous location installations.
Be sure that power is removed or the area is nonhazardous before proceeding.
Wire Specifications for Input Power Terminal Block
Wire Type Dual-wire Gauge
(1)
(1)
Two-wire maximum per terminal.
Single-wire
Gauge
Terminal Screw
Torque
Stranded or solid Cu 90 °C (194 °F) 0.33…1.31 mm
2
(22…16 AWG)
0.33…2.08 mm
2
(22…14 AWG)
0.45…0.56 Nm
(4…5 lb-in.)
ATTENTION: Disconnect all power before installing or replacing components. Failure to
disconnect power may result in electrical shock or damage to the terminal.
