Allen-Bradley POINT I/O series User Manual

18 POINT I/O 2 and 4 Relay Output Modules
Publication 1734-IN055H-EN-E - August 2016
Wire Using a 1734-FPD
Wire Using External Power Source for AC Relay Power
01
23
45
67
01
23
45
67
01
23
45
67
01
23
45
67
01
23
45
67
01
23
45
67
01
23
45
67
01
23
45
67
01
23
45
67
PDN
IB2 IB4
IV2 IV4 FPD
OW2
AC
power
bus
C V L2/N L1
45187
OW2
OW2
01 01 0101 01010101
2323232323232323
4545454545454545
6767676767676767
PDN
IB2 IV2
IB4 IV4
OW2
OW2
OW2
24V L2/N L1
120V AC/240V AC
45726

Allen-Bradley POINT I/O series Specifications

General

Series	POINT I/O
Category	Control Unit
Mounting Type	DIN Rail
Manufacturer	Allen-Bradley
Communication Interface	EtherNet/IP, DeviceNet, ControlNet, PROFIBUS DP
Storage Temperature Range	-40°C to 85°C (-40°F to 185°F)
Relative Humidity	5% to 95% (non-condensing)
Shock Resistance	30g (11ms duration)
Vibration Resistance	5G
Certifications	CE, UL, ATEX, IECEx
IP Rating	IP20
