Allen-Bradley PowerFlex 20-750-DCBB2-F6 Programming Manual

166 Rockwell Automation Publication 750-PM001N-EN-P - February 2017
Chapter 3 Drive Port 0 Parameters
DIAGNOSTICS
Fault/Alarm Info
962 AlarmA at Fault
Alarm A at Fault
RO 32-bit
Integer
Captures and displays P959 [Alarm Status A] at the time of the last fault.
For some alarms, the value captured in this parameter may not match peak/low at time of fault due to data latency.
For details on alarms and faults, refer to Chapter 6
.
Bit 0 “Power Loss” – A Power Loss exception has been issued.
Bit 1 “UnderVoltage” – An Under Voltage exception has been issued.
Bit 2 “Motor OL” – An excessive motor load exists.
Bit 4 “InPhaseLoss” – Input Phase Loss exception has been issued.
Bit 5 “OutPhaseLoss” – Output Phase Loss exception has been issued.
Bit 6 “Decel Inhib” – The drive is being Inhibited from decelerating to the commanded speed.
Bit 7 “Shear Pin 1” – Value set in P436 [Shear Pin1 Level] has been exceeded.
Bit 8 “Shear Pin 2” – Value set in P439 [Shear Pin2 Level] has been exceeded.
Bit 9 “PriFdbkLoss” – When set, indicates that the device selected as the primary velocity feedback source has reported a device failure. P125 [Pri Vel Fdbk Sel]
selects the device used as the primary velocity feedback source. The primary feedback device supplies motor speed feedback if the Automatic Tach Switchover
option is either disabled or has not switched to the alternate feedback device. In order to report this condition as an alarm, the feedback loss configuration
parameter for the primary feedback device must be configured for “Alarm.”
Bit 10 “AltFdbkLoss” – When set, indicates that the device selected as the alternate velocity feedback source has reported a device failure. P128 [Alt Vel Fdbk Sel]
selects the device used as the alternate velocity feedback source. The alternate feedback device supplies motor speed feedback if the Automatic Tach Switchover
option is enabled and the primary feedback device has failed. In order to report this condition as an alarm, the feedback loss configuration parameter for the
alternate feedback device must be configured for “Alarm.”
Bit 11 “AuxFdbkLoss” – When set, indicates that the device selected as the auxiliary velocity feedback source has reported a device failure. P132 [Aux Vel Fdbk Sel]
selects the device used as the auxiliary velocity feedback source. The auxiliary feedback device can be used to supply motor speed reference. In order to report this
condition as an alarm, the feedback loss configuration parameter for the auxiliary feedback device must be configured for “Alarm.”
Bit 12 “PosFdbkLoss” – When set, indicates that the device selected as the position feedback source has reported a device failure. P135 [Psn Fdbk Sel] selects the
device used as the position feedback source. Position feedback is used for position control applications. It can be the same device used for velocity feedback or
position feedback can be supplied by a separate device. In order to report this condition as an alarm, the feedback loss configuration parameter for the position
feedback device must be configured for “Alarm.”
Bit 14 “GndWarning” – Value set in P467 [Ground Warn Lvl] has been exceeded.
Bit 15 “Task Overrun” – System resource utilization has been exceeded. See System Resource Allocation
on page 307 for details.
963 AlarmB at Fault
Alarm B at Fault
RO 32-bit
Integer
Captures and displays P960 [Alarm Status B] at the time of the last fault.
See parameter 960 [Alarm Status B] for bit descriptions.
For some alarms, the value captured in this parameter may not match peak/low at time of fault due to data latency.
For details on alarms and faults, refer to Chapter 6
.
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Task Overrun Gnd Warning Reserved PosFdbkLoss AuxFdbkLoss AltFdbkLoss PriFdbkLoss Shear Pin 2 Shear Pin 1 Decel Inhib OutPhaseLoss InPhaseLoss Load Loss Motor OL UnderVoltage Power Loss
Default00000000000000000000000000000000
Bit 313029282726252423222120191817161514131211109876543210
0 = Condition False
1 = Condition True
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved DB Res OT N-1 Operate PumpOff Alrm OW Alarm TO OW Level Gnd Warning Not Home Set Homing Actv Profile Actv
(1)
(1) 755 drives only.
PWMFrq Reduc CurLmt Reduc Drive OL StartOnPwrUp Waking Heatsink OT IGBT OT
Default00000000000000000000000000000000
Bit 313029282726252423222120191817161514131211109876543210
0 = Condition False
1 = Condition True
