Rockwell Automation Publication 750-PM001N-EN-P - February 2017 37
Parameter Organization Chapter 2
Inverter Common (Port 10)
Inverter Common parameters are only used by PowerFlex 755 Frame 8 and larger
drives.
Parameter descriptions begin on page 212
.
Inverter n (Port 10)
Inverter n parameters are only used by PowerFlex 755 Frame 8 and larger drives.
Parameter descriptions begin on page 214
.
File Group Parameters
Inverter Common System Ratings Sys Rated Amps 1
Sys Rated Volts 2
I1 Rated Amps 3
I2 Rated Amps 4
I3 Rated Amps 5
Status Online Status 10 Fault Status 12 Alarm Status 13
Metering Ground Current 18 Recfg Acknowledg 20 Effctv I Rating 21
Testpoints Testpoint Sel 1 30Testpoint Val 1 31Testpoint Sel 2 32Testpoint Val 2 33
Inverter Common
File Group Parameters
Inverter n Status I1 Fault Status 105
I1 Alarm Status 107
I2 Fault Status 205
I2 Alarm Status 207
I3 Fault Status 305
I3 Alarm Status 307
Metering I1 U Phase Curr 115
I1 V Phase Curr 116
I1 W Phase Curr 117
I1 Gnd Current 118
I1 DC Bus Volt 119
I1 Heatsink Temp 120
I1 IGBT Temp 121
I1 HSFan Speed 124
I1 InFan 1 Speed 125
I1 InFan 2 Speed 126
I2 U Phase Curr 215
I2 V Phase Curr 216
I2 W Phase Curr 217
I2 Gnd Current 218
I2 DC Bus Volt 219
I2 Heatsink Temp 220
I2 IGBT Temp 221
I2 HSFan Speed 224
I2 InFan 1 Speed 225
I2 InFan 2 Speed 226
I3 U Phase Curr 315
I32 V Phase Curr 316
I3 W Phase Curr 317
I3 Gnd Current 318
I3 DC Bus Volt 319
I3 Heatsink Temp 320
I3 IGBT Temp 321
I3 HSFan Speed 324
I3 InFan 1 Speed 325
I3 InFan 2 Speed 326
Predictive Main I1 PredMainReset 127
I1 HSFanElpsdLif 128
I1 InFanElpsdLif 129
I2 PredMainReset 227
I2 HSFanElpsdLif 228
I2 InFanElpsdLif 229
I3 PredMainReset 327
I3 HSFanElpsdLif 328
I3 InFanElpsdLif 329
Testpoints I1 Testpt Sel 1 140
I1 Testpt Val 1 141
I1 Testpt Sel 2 142
I1 Testpt Val 2 143
I2 Testpt Sel 1 240
I2 Testpt Val 1 241
I2 Testpt Sel 2 242
I2 Testpt Val 2 243
I3 Testpt Sel 1 340
I3 Testpt Val 1 341
I3 Testpt Sel 2 342
I3 Testpt Val 2 343
Inverter n
