38 Rockwell Automation Publication 750-PM001N-EN-P - February 2017
Chapter 2 Parameter Organization
Converter Common (Port 11)
Converter Common parameters are only used by AC input PowerFlex 755 Frame
8 and larger drives.
Parameter descriptions begin on page 217
.
Converter n (Port 11)
Converter n parameters are only used by AC input PowerFlex 755 Frame 8 and
larger drives.
Parameter descriptions begin on page 220
.
File Group Parameters
Converter
Common
System Ratings Sys Rated Amps 1
Sys Rated Volts 2
C1 Rated Amps 3
C2 Rated Amps 4
C3 Rated Amps 5
Status Online Status 10 Fault Status 12 Alarm Status 13
Configuration Gnd Cur Flt Lvl 16 Converter Actn 17
Metering L1 Phase Curr 20
L2 Phase Curr 21
L3 Phase Curr 22
Heatsink Temp 23
SCR Temp 24
Gate Board Temp 25
Testpoints Testpoint Sel 1 30
Testpoint Val 1 31
Testpoint Sel 2 32
Testpoint Val 2 33
Converter Common
File Group Parameters
Converter n Status C1 Fault Status1 105
C1 Fault Status2 106
C1 Alarm Status1 107
C2 Fault Status1 205
C2 Fault Status2 206
C2 Alarm Status1 207
C3 Fault Status1 305
C3 Fault Status2 306
C3 Alarm Status1 307
Metering C1 L1 Phase Curr 115
C1 L2 Phase Curr 116
C1 L3 Phase Curr 117
C1 Gnd Current 118
C1 DC Bus Volt 119
C1 Heatsink Temp 120
C1 SCR Temp 121
C1 GateBoardTemp 122
C1 AC Line Freq 123
C1 L12 Line Volt 125
C1 L23 Line Volt 126
C1 L31 Line Volt 127
C2 L1 Phase Curr 215
C2 L2 Phase Curr 216
C2 L3 Phase Curr 217
C2 Gnd Current 218
C2 DC Bus Volt 219
C2 Heatsink Temp 220
C2 SCR Temp 221
C2 GateBoardTemp 222
C2 AC Line Freq 223
C2 L12 Line Volt 225
C2 L23 Line Volt 226
C2 L31 Line Volt 227
C3 L1 Phase Curr 315
C3 L2 Phase Curr 316
C3 L3 Phase Curr 317
C3 Gnd Current 318
C3 DC Bus Volt 319
C3 Heatsink Temp 320
C3 SCR Temp 321
C3 GateBoardTemp 322
C3 AC Line Freq 323
C3 L12 Line Volt 325
C3 L23 Line Volt 326
C3 L31 Line Volt 327
Predictive Main C1 PredMainReset 137
C1 CbFanElpsdLif 138
C2 PredMainReset 237
C2 CbFanElpsdLif 238
C3 PredMainReset 337
C3 CbFanElpsdLif 338
Testpoints C1 Testpt Sel 1 140
C1 Testpt Val 1 141
C1 Testpt Sel 2 142
C1 Testpt Val 2 143
C2 Testpt Sel 1 240
C2 Testpt Val 1 241
C2 Testpt Sel 2 242
C2 Testpt Val 2 243
C3 Testpt Sel 1 340
C3 Testpt Val 1 341
C3 Testpt Sel 2 342
C3Testpt Val 2 343
Converter n
