Rockwell Automation Publication 750-PM001N-EN-P - February 2017 525
Integrated Motion on EtherNet/IP Application Appendix F
Precharge Parameter / Enhanced Attribute Mapping
Table 36 - PowerFlex 755 Common Bus Precharge Parameter Numeric Order
Encoder Parameter / Enhanced Attribute Mapping
Table 37 - Universal Feedback Encoder Module Output Parameter Numeric Order
13 Alarm Status 2914 B62 Alarm Status INT
25 Gate Board Temp 2916 B64 Gate Board Temp Real
30 Testpoint Sel 1 2917 B65 Testpoint Sel 1 DINT
31 Testpoint Val 1 2918 B66 Testpoint Val 1 Real
32 Testpoint Sel 2 2919 B67 Testpoint Sel 2 DINT
33 Testpoint Val 2 2920 B68 Testpoint Val 2 Real
Drive Integrated Motion
Parameter No. Parameter Name Base 10 Base 16 Enhanced Attribute Data Type
1 Sys Rated Amps 2955 B8B Sys Rated Amps Real
2 Sys Rated Volts 2956 B8C Sys Rated Volts Real
3 P1 Rated Amps 2957 B8D PX1 Rated Amps Real
4 P2 Rated Amps 2958 B8E PX2 Rated Amps Real
5 P3 Rated Amps 2959 B8F PX3 Rated Amps Real
10 Online Status 2962 B92 Online Status INT
12 Fault Status 2963 B93 Fault Status INT
13 Alarm Status 2964 B94 Alarm Status INT
18 Main DC Bus Volt 2965 B95 Main DC Bus Volt Real
25 Gate Board Temp 2966 B96 Gate Board Temp Real
30 Testpoint Sel 1 2967 B97 Testpoint Sel 1 DINT
31 Testpoint Val 1 2968 B98 Testpoint Val 1 Real
32 Testpoint Sel 2 2969 B99 Testpoint Sel 2 DINT
33 Testpoint Val 2 2970 B9A Testpoint Val 2 Real
Drive Integrated Motion
Parameter No. Parameter Name Base 10 Base 16 Enhanced Attribute Data Type
80 Enc Out Sel 2800 AF0 Enc Out Sel DINT
81 Enc Out Mode 2801 AF1 Enc Out Mode DINT
82 Enc Out FD PPR 2802 AF2 Enc Out FD PPR DINT
83 Enc Out Z Offset 2803 AF3 Enc Out Z Offset DINT
84 Enc Out Z PPR 2804 AF4 Enc Out Z PPR DINT
20, Bit 4 FB0 SSI Cfg 2805 AF5 FB0 SSI Cfg, Double Word Query SINT
50, Bit 4 FB1 SSI Cfg 2806 AF6 FB1 SSI Cfg, Double Word Query SINT
Table 35 - PowerFlex 755 Converter Parameter Numeric Order (Continued)
Drive Integrated Motion
Parameter No. Parameter Name Base 10 Base 16 Enhanced Attribute Data Type
