524 Rockwell Automation Publication 750-PM001N-EN-P - February 2017
Appendix F Integrated Motion on EtherNet/IP Application
Inverter Parameter / Enhanced Attribute Mapping
Table 34 - PowerFlex 755 Inverter Parameter Numeric Order
Converter Parameter / Enhanced Attribute Mapping
1544 VB Min Freq 2713 A99 VB Min Freq Real
1545 VB Flux Thresh 2714 A9A VB Flux Thresh Real
1546 VB Flux Lag Freq 2715 A9B VB Flux Lag Freq Real
1547 VB Filt Flux Cur 2716 A9C VB Filt Flux Cur Real
1548 VB Current Rate 2717 A9D VB Current Rate Real
1549 VB Current Hyst 2718 A9E VB Current Hyst Real
1550 VB Cur Thresh 2719 A9F VB Cur Thresh Real
1551 VB Rate Lag Freq 2720 AA0 VB Rate Lag Freq Real
Drive Integrated Motion
Parameter No. Parameter Name Base 10 Base 16 Enhanced Attribute Data Type
1 Sys Rated Amps 2855 B27 Sys Rated Amps Real
2 Sys Rated Volts 2856 B28 Sys Rated Volts Real
3 I1 Rated Amps 2857 B29 Ix1 Rated Amps Real
4 I2 Rated Amps 2858 B2A Ix2 Rated Amps Real
5 I3 Rated Amps 2859 B2B Ix3 Rated Amps Real
10 Online Status 2862 B2E Online Status INT
12 Fault Status 2863 B2F Fault Status INT
13 Alarm Status 2864 B30 Alarm Status INT
18 Ground Current 2865 B31 Ground Current Real
20 Recfg Acknowledg 2866 B32 Recfg Acknowledg DINT
21 Effctv I Rating 2867 B33 Effctv I Rating Real
30 Testpoint Sel 1 2868 B34 Testpoint Sel 1 DINT
31 Testpoint Val 1 2869 B35 Testpoint Val 1 Real
32 Testpoint Sel 2 2870 B36 Testpoint Sel 2 DINT
33 Testpoint Val 2 2871 B37 Testpoint Val 2 Real
Table 35 - PowerFlex 755 Converter Parameter Numeric Order
Drive Integrated Motion
Parameter No. Parameter Name Base 10 Base 16 Enhanced Attribute Data Type
1 Sys Rated Amps 2905 B59 Sys Rated Amps Real
2 Sys Rated Volts 2906 B5A Sys Rated Volts Real
3 C1 Rated Amps 2907 B5B CX1 Rated Amps Real
4 C2 Rated Amps 2908 B5C CX2 Rated Amps Real
5 C3 Rated Amps 2909 B5D CX3 Rated Amps Real
10 Online Status 2912 B60 Online Status INT
12 Fault Status 2913 B61 Fault Status INT
Drive Integrated Motion
Parameter No. Parameter Name Base 10 Base 16 Enhanced Attribute Data Type
