30 Rockwell Automation Publication 520-QS001A-EN-E - March 2014
PowerFlex 520-Series Adjustable Frequency AC Drive
F033 Auto Rstrt Tries Correct the cause of the fault and manually clear.
F038 Phase U to Gnd Check the wiring between the drive and motor.
Check motor for grounded phase.
Replace drive if fault cannot be cleared.
F039 Phase V to Gnd
F040 Phase W to Gnd
F041 Phase UV Short Check the motor and drive output terminal wiring for a shorted condition.
Replace drive if fault cannot be cleared.
F042 Phase UW Short
F043 Phase VW Short
F048 Params Defaulted Clear the fault or cycle power to the drive.
Program the drive parameters as needed.
F059
(1)
Safety Open Check safety input signals. If not using safety, verify and tighten jumper for I/O terminals S1, S2 and S+.
F063 SW OverCurrent Verify connections between motor and load.
Verify level and time requirements.
F064 Drive Overload Reduce load or extend Accel Time.
F070 Power Unit Check maximum ambient temperature has not been exceeded.
Cycle power.
Replace drive if fault cannot be cleared.
F071 DSI Net Loss Cycle power.
Check communications cabling.
Check Modbus or DSI setting.
Check Modbus or DSI status.
F072 Opt Net Loss Cycle power.
Check communications cabling.
Check network adapter setting.
Check external network status.
F073
(1)
EN Net Loss Cycle power.
Check communications cabling.
Check EtherNet/IP setting.
Check external network status.
F080 Autotune Failure Restart procedure.
F081 DSI Comm Loss Cycle power.
Check communications cabling.
Check Modbus or DSI setting.
Check Modbus or DSI status.
Modify using C125 [Comm Loss Action].
Connecting I/O terminals C1 and C2 to ground may improve noise immunity.
Replace wiring, Modbus master device, or control module.
F082 Opt Comm Loss Cycle power.
Reinstall option card in drive.
Modify using C125 [Comm Loss Action].
Replace wiring, port expander, option card, or control module.
F083
(1)
EN Comm Loss Cycle power.
Check EtherNet/IP setting.
Check drive’s Ethernet settings and diagnostic parameters.
Modify using C125 [Comm Loss Action].
Replace wiring, Ethernet switch, or control module.
F091
(1)
Encoder Loss Check Wiring.
If P047, P049, P051 [Speed Referencex] = 16 “Positioning” and A535 [Motor Fdbk Type] = 5 “Quad Check”, swap the Encoder channel inputs or
swap any two motor leads.
Replace encoder.
F094 Function Loss Close input to the terminal and cycle power.
F100 Parameter Chksum Set P053 [Reset To Defalts] to 2 “Factory Rset.
F101 External Storage Set P053 [Reset To Defalts] to 2 “Factory Rset”.
F105 C Connect Err Clear fault and verify all parameter settings. Do not remove or install the control module while power is applied.
F106 Incompat C-P Change to a different power module.
Change to a PowerFlex 523 control module.
F107 Replaced C-P Change to a different power module.
Replace control module if changing power module does not work.
No. Fault Action
