Allen-Bradley PowerFlex 523 Quick Start

Rockwell Automation Publication 520-QS001A-EN-E - March 2014 31
PowerFlex 520-Series Adjustable Frequency AC Drive
Drive Ratings
F109 Mismatch C-P Set P053 [Reset To Defalts] to 3 “Power Reset”.
F110 Keypad Membrane • Cycle power.
• Replace control module if fault cannot be cleared.
F111
(1)
Safety Hardware • Check safety input signals. If not using safety, verify and tighten jumper for I/O terminals S1, S2 and S+.
• Replace control module if fault cannot be cleared.
F114 uC Failure • Cycle power.
• Replace control module if fault cannot be cleared.
F122 I/O Board Fail • Cycle power.
• Replace drive or control module if fault cannot be cleared.
F125 Flash Update Req Perform a firmware flash update operation to attempt to load a valid set of firmware.
F126 NonRecoverablErr • Clear fault or cycle power to the drive.
• Replace drive or control module if fault cannot be cleared.
F127 DSIFlashUpdatReq Perform a firmware flash update operation using DSI communications to attempt to load a valid set of firmware.
(1) This fault is not applicable to PowerFlex 523 drives.
PowerFlex 523 Frames – Ratings are in kW and (HP).
Frame
1-Phase
100...120V
1-Phase
200...240V
1-Phase
200...240V
w/ Filter
3-Phase
200...240V
3-Phase
380...480V
3-Phase
380...480V
w/ Filter
3-Phase
525...600V
A 0.2...0.4 (0.25...0.5) 0.2...0.75 (0.25...1.0) 0.2...0.75 (0.25...1.0) 0.2...2.2 (0.25...3.0) 0.4...2.2 (0.5...3.0) 0.4...2.2 (0.5...3.0) 0.4...2.2 (0.5...3.0)
B 0.75...1.1 (1.0...1.5) 1.5...2.2 (2.0...3.0) 1.5...2.2 (2.0...3.0) 4.0 (5.0) 4.0 (5.0) 4.0 (5.0) 4.0 (5.0)
C – – – 5.5 (7.5) 5.5...7.5 (7.5...10.0) 5.5...7.5 (7.5...10.0) 5.5...7.5 (7.5...10.0)
D – – – 7.5 (10.0) 11.0...15.0 (15.0...20.0) 11.0...15.0 (15.0...20.0) 11.0...15.0 (15.0...20.0)
E – – – 11.0...15.0 (15.0...20.0) – 18.5...22.0 (25.0...30.0) 18.5...22.0 (25.0...30.0)
PowerFlex 525 Frames – Ratings are in kW and (HP).
Frame
1-Phase
100...120V
1-Phase
200...240V
1-Phase
200...240V
w/ Filter
3-Phase
200...240V
3-Phase
380...480V
3-Phase
380...480V
w/ Filter
3-Phase
525...600V
A 0.4 (0.5) 0.4...0.75 (0.5...1.0) 0.4...0.75 (0.5...1.0) 0.4...2.2 (0.5...3.0) 0.4...2.2 (0.5...3.0) 0.4...2.2 (0.5...3.0) 0.4...2.2 (0.5...3.0)
B 0.75...1.1 (1.0...1.5) 1.5...2.2 (2.0...3.0) 1.5...2.2 (2.0...3.0) 4.0 (5.0) 4.0 (5.0) 4.0 (5.0) 4.0 (5.0)
C – – – 5.5 (7.5) 5.5...7.5 (7.5...10.0) 5.5...7.5 (7.5...10.0) 5.5...7.5 (7.5...10.0)
D – – – 7.5 (10.0) 11.0...15.0 (15.0...20.0) 11.0...15.0 (15.0...20.0) 11.0...15.0 (15.0...20.0)
E – – – 11.0...15.0 (15.0...20.0) – 18.5...22.0 (25.0...30.0) 18.5...22.0 (25.0...30.0)
No. Fault Action
