Allen-Bradley PowerFlex 525 User Manual

Rockwell Automation Publication 520-UM001G-EN-E - September 2014 113
Programming and Parameters Chapter 3
Advanced Program Group (continued)
A456 [PID 1 Trim Hi]
A468 [PID 2 Trim Hi]
PowerFlex 525 only.
Scales the upper value of the trim frequency when trim is active.
Values Default: 60.0 Hz
Min/Max: 0.0/500.0 Hz
Display: 0.1 Hz
PF 525
A457 [PID 1 Trim Lo]
A469 [PID 2 Trim Lo]
PowerFlex 525 only.
Scales the lower value of the trim frequency when trim is active.
Values Default: 0.0 Hz
Min/Max: 0.0/500.0 Hz
Display: 0.1 Hz
PF 525
A458 [PID 1 Trim Sel]
A470 [PID 2 Trim Sel]
PowerFlex 525 only.
Stop drive before changing this parameter.
Sets the PID output as trim to the source reference.
Options 0 “Disabled” (Default) PID Trim is disabled.
1“TrimOn Pot”
2 “TrimOn Keypd”
3“TrimOn DSI”
4“TrimOn NetOp”
5 “TrimOn 0-10V”
6 “TrimOn 4-20”
7“TrimOn Prset”
8“TrimOn AnMlt”
(1)
9“TrimOn MOP”
10 “TrimOn Pulse”
11 “TrimOn Slgic”
(1)
12 “TrimOn Encdr”
(1)
13 “TrimOn ENet”
(1)
(1) Setting is specific to PowerFlex 525 drives only.
PF 525

Allen-Bradley PowerFlex 525 Specifications

General

Horsepower	0.5-30 HP
kW	0.4-22 kW
Input Voltage	200-240V AC, 380-480V AC
Enclosure	IP20, NEMA/UL Type 1
Communications	EtherNet/IP
Control Methods	V/Hz, Sensorless Vector
STO	Safe Torque Off (STO)
Output Voltage	0-Input Voltage
Operating Temperature	-20°C to 50°C (-4°F to 122°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)
Relative Humidity	5-95% non-condensing
Dimensions	Varies by model
Weight	Varies by model
