Chapter 3 Programming and Parameters
AppView Parameter Groups
PowerFlex 520-series drives include various AppView™ parameter groups that
groups certain parameters together for quick and easy access based on different
types of applications. See AppView Parameter Groups
on page 138 for more
information.
Fault and Diagnostic
Fault 4 Code F604
Fault 5 Code F605
Fault 6 Code F606
Fault 7 Code F607
Fault 8 Code F608
Fault 9 Code F609
Fault10 Code F610
Fault 1 Time-hr F611
Fault 2 Time-hr F612
Fault 3 Time-hr F613
Fault 4 Time-hr F614
Fault 5 Time-hr F615
Fault 6 Time-hr
(1)
F616
Fault 7 Time-hr
(1)
F617
Fault 8 Time-hr
(1)
F618
Fault 9 Time-hr
(1)
F619
Fault10 Time-hr
(1)
F620
Fault 1 Time-min F621
Fault 2 Time-min F622
Fault 3 Time-min F623
Fault 4 Time-min F624
Fault 5 Time-min F625
Fault 6 Time-min
(1)
F626
Fault 7 Time-min
(1)
F627
Fault 8 Time-min
(1)
F628
Fault 9 Time-min
(1)
F629
Fault10 Time-min
(1)
F630
Fault 1 Freq F631
Fault 2 Freq F632
Fault 3 Freq F633
Fault 4 Freq F634
Fault 5 Freq F635
Fault 6 Freq
(1)
F636
Fault 7 Freq
(1)
F637
Fault 8 Freq
(1)
F638
Fault 9 Freq
(1)
F639
Fault10 Freq
(1)
F640
Fault 1 Current F641
Fault 2 Current F642
Fault 3 Current F643
Fault 4 Current F644
Fault 5 Current F645
Fault 6 Current
(1)
F646
Fault 7 Current
(1)
F647
Fault 8 Current
(1)
F648
Fault 9 Current
(1)
F649
Fault10 Current
(1)
F650
Fault 1 BusVolts F651
Fault 2 BusVolts F652
Fault 3 BusVolts F653
Fault 4 BusVolts F654
Fault 5 BusVolts F655
Fault 6 BusVolts
(1)
F656
Fault 7 BusVolts
(1)
F657
Fault 8 BusVolts
(1)
F658
Fault 9 BusVolts
(1)
F659
Fault10 BusVolts
(1)
F660
Status @ Fault 1 F661
Status @ Fault 2 F662
Status @ Fault 3 F663
Status @ Fault 4 F664
Status @ Fault 5 F665
Status @ Fault 6
(1)
F666
Status @ Fault 7
(1)
F667
Status @ Fault 8
(1)
F668
Status @ Fault 9
(1)
F669
Status @ Fault10
(1)
F670
Comm Sts - DSI F681
Comm Sts - Opt F682
Com Sts-Emb Enet
(1)
F683
EN Addr Src
(1)
F684
EN Rate Act
(1)
F685
DSI I/O Act F686
HW Addr 1
(1)
F687
HW Addr 2
(1)
F688
HW Addr 3
(1)
F689
HW Addr 4
(1)
F690
HW Addr 5
(1)
F691
HW Addr 6
(1)
F692
EN IP Addr Act 1
(1)
F693
EN IP Addr Act 2
(1)
F694
EN IP Addr Act 3
(1)
F695
EN IP Addr Act 4
(1)
F696
EN Subnet Act 1
(1)
F697
EN Subnet Act 2
(1)
F698
EN Subnet Act 3
(1)
F699
EN Subnet Act 4
(1)
F700
EN Gateway Act 1
(1)
F701
EN Gateway Act 2
(1)
F702
EN Gateway Act 3
(1)
F703
EN Gateway Act 4
(1)
F704
Drv 0 Logic Cmd F705
Drv 0 Reference F706
Drv 0 Logic Sts F707
Drv 0 Feedback F708
Drv 1 Logic Cmd F709
Drv 1 Reference F710
Drv 1 Logic Sts F711
Drv 1 Feedback F712
Drv 2 Logic Cmd F713
Drv 2 Reference F714
Drv 2 Logic Sts F715
Drv 2 Feedback F716
Drv 3 Logic Cmd F717
Drv 3 Reference F718
Drv 3 Logic Sts F719
Drv 3 Feedback F720
Drv 4 Logic Cmd F721
Drv 4 Reference F722
Drv 4 Logic Sts F723
Drv 4 Feedback F724
EN Rx Overruns
(1)
F725
EN Rx Packets
(1)
F726
EN Rx Errors
(1)
F727
EN Tx Packets
(1)
F728
EN Tx Errors
(1)
F729
EN Missed IO Pkt
(1)
F730
DSI Errors F731
(1) Parameter is specific to PowerFlex 525 drives only.
Conveyor
Language P030
Output Freq b001
Commanded Freq b002
Motor NP Volts P031
Motor NP Hertz P032
Motor OL Current P033
Motor NP FLA P034
Motor NP Poles P035
Autotune P040
Accel Time 1 P041
Decel Time 1 P042
Minimum Freq P043
Maximum Freq P044
Stop Mode P045
Start Source 1 P046
Speed Reference1 P047
DigIn TermBlk 02 t062
DigIn TermBlk 03 t063
Opto Out1 Sel t069
Relay Out1 Sel t076
Anlg In 0-10V Lo t091
Anlg In 0-10V Hi t092
Anlg In4-20mA Lo t095
Anlg In4-20mA Hi t096
Anlg In mA Loss t097
Slip Hz Meter d375
Preset Freq 0 A410
Jog Frequency A431
Jog Accel/Decel A432
S Curve % A439
Reverse Disable A544
Mixer
Language P030
Output Freq b001
Commanded Freq b002
Output Current b003
Motor NP Volts P031
Motor NP Hertz P032
Motor OL Current P033
Motor NP FLA P034
Motor NP Poles P035
Autotune P040
Accel Time 1 P041
Decel Time 1 P042
Minimum Freq P043
Maximum Freq P044
Stop Mode P045
Start Source 1 P046
Speed Reference1 P047
Relay Out1 Sel t076
Anlg In 0-10V Lo t091
Anlg In 0-10V Hi t092
Anlg In4-20mA Lo t095
Anlg In4-20mA Hi t096
Anlg In mA Loss t097
Preset Freq 0 A410
Stall Fault Time A492
Compressor
Language P030
Output Freq b001
Commanded Freq b002
Motor NP Volts P031
Motor NP Hertz P032
Motor OL Current P033
Motor NP FLA P034
Motor NP Poles P035
Autotune P040
Accel Time 1 P041
Decel Time 1 P042
Minimum Freq P043
Maximum Freq P044
Stop Mode P045
Start Source 1 P046
Speed Reference1 P047
Relay Out1 Sel t076
Analog Out Sel t088
Analog Out High t089
Anlg Out Setpt t090
Anlg In 0-10V Lo t091
Anlg In 0-10V Hi t092
Anlg In4-20mA Lo t095
Anlg In4-20mA Hi t096
Anlg In mA Loss t097
Preset Freq 0 A410
Auto Rstrt Tries A541
Auto Rstrt Delay A542
Start At PowerUp A543
Reverse Disable A544
Power Loss Mode A548
Half Bus Enable A549
