Allen-Bradley PowerFlex 525 User Manual

86 Rockwell Automation Publication 520-UM001G-EN-E - September 2014
Chapter 3 Programming and Parameters
Terminal Block Group (continued)
t070 [Opto Out1 Level] Related Parameter(s): t069, t072
t073 [Opto Out2 Level]
32 bit parameter.
PowerFlex 525 only.
Determines the on/off point for the digital outputs when t069 or t072 [Opto Outx Sel] is set to the values shown below.
Values Default: 0
Min/Max: 0/9999
Display: 1
PF 525
Min/Max Value Range Based On [Opto Outx Sel] Setting
6: 0...500 Hz 10: 0...100% 16: 0.1...9999 s 20: 0/1
7: 0...180% 11 0/1 17: 1...9999 counts 26: 0...150%
8: 0...815V 13 0...800 18: 0...180° –
t075 [Opto Out Logic]
PowerFlex 525 only.
Determines the logic (Normally Open/NO or Normally Closed/NC) of the digital outputs only.
Values Default: 0
Min/Max: 0/3
Display: 1
PF 525
Setting Digital Out 1 Logic Digital Out 2 Logic
0NO NO
1NC NO
2NO NC
3NC NC
