14 Rockwell Automation Publication 520-TD002A-EN-E - May 2015
PowerFlex 527 AC Drive Specifications
(1) A non-filtered drive is not available for 380...480V AC 25 HP (18.5 kW) and 30 HP (22.0 kW) ratings. Filtered drives are available, however you must verify that the application will support a filtered drive.
(2) Catalogs 25C-037N114 and 25C-043N114 come with an EMC filter.
Catalog No.
Output Ratings
Input Voltage Range Total Watts Loss Frame Size
Normal Duty Heavy Duty
Output Current (A)HP kW HP kW
380...480V AC (-15%, +10%) – 3-Phase Input with EMC Filter, 0...460V 3-Phase Output
25C-D1P4N114 0.5 0.4 0.5 0.4 1.4 323...528 27.0 A
25C-D2P3N114 1.0 0.75 1.0 0.75 2.3 323...528 37.0 A
25C-D4P0N114 2.0 1.5 2.0 1.5 4.0 323...528 81.0 A
25C-D6P0N114 3.0 2.2 3.0 2.2 6.0 323...528 88.0 A
25C-D010N114 5.0 4.0 5.0 4.0 10.5 323...528 133.0 B
25C-D013N114 7.5 5.5 7.5 5.5 13.0 323...528 175.0 C
25C-D017N114 10.0 7.5 10.0 7.5 17.0 323...528 230.0 C
25C-D024N114 15.0 11.0 15.0 11.0 24.0 323...528 313.0 D
25C-D030N114 20.0 15.0 15.0 11.0 30.0 323...528 402.0 D
25C-D037N114 25.0 18.5 20.0 15.0 37.0 323...528 602.0 E
25C-D043N114 30.0 22.0 25.0 18.5 43.0 323...528 697.0 E
525...600V AC (-15%, +10%) – 3-Phase Input, 0...575V 3-Phase Output
25C-E0P9N104 0.5 0.4 0.5 0.4 0.9 446...660 22.0 A
25C-E1P7N104 1.0 0.75 1.0 0.75 1.7 446...660 32.0 A
25C-E3P0N104 2.0 1.5 2.0 1.5 3.0 446...660 50.0 A
25C-E4P2N104 3.0 2.2 3.0 2.2 4.2 446...660 65.0 A
25C-E6P6N104 5.0 4.0 5.0 4.0 6.6 446...660 95.0 B
25C-E9P9N104 7.5 5.5 7.5 5.5 9.9 446...660 138.0 C
25C-E012N104 10.0 7.5 10.0 7.5 12.0 446...660 164.0 C
25C-E019N104 15.0 11.0 15.0 11.0 19.0 446...660 290.0 D
25C-E022N104 20.0 15.0 15.0 11.0 22.0 446...660 336.0 D
25C-E027N104 25.0 18.5 20.0 15.0 27.0 446...660 466.0 E
25C-E032N104 30.0 22.0 25.0 18.5 32.0 446...660 562.0 E
