PowerFlex 527 AC Drive Specifications
(1) EMC Line Filter size is based on the input current of the drive. See the tables on page 29 and page 30 for more information.
(2) This 600V drive rating needs to be matched with a frame B EMC Line Filter.
EMC Line Filters
Drive Ratings
Frame Size Catalog No.Input Voltage HP kW Current (A)
100...120V
50/60 Hz
1-Phase
0.5 0.4 2.5 A 25-RF011-AL
1.0 0.75 4.8 B 25-RF023-BL
1.5 1.1 6.0 B 25-RF023-BL
200...240V
50/60 Hz
1-Phase
0.5 0.4 2.5 A 25-RF011-AL
1.0 0.75 4.8 A 25-RF011-AL
2.0 1.5 8.0 B 25-RF023-BL
3.0 2.2 11.0 B 25-RF023-BL
200...240V
50/60 Hz
3-Phase
0.5 0.4 2.5 A 25-RF014-AL
1.0 0.75 5.0 A 25-RF014-AL
2.0 1.5 8.0 A 25-RF014-AL
3.0 2.2 11.0 A 25-RF014-AL
5.0 4.0 17.5 B 25-RF021-BL
7.5 5.5 24.0 C 25-RF027-CL
10.0 7.5 32.2 D 25-RF035-DL
15.0 11.0 48.3 E 25-RF056-EL
20.0 15.0 62.1 E 25-RF056-EL
380...480V
50/60 Hz
3-Phase
0.5 0.4 1.4 A 25-RF7P5-AL
1.0 0.75 2.3 A 25-RF7P5-AL
2.0 1.5 4.0 A 25-RF7P5-AL
3.0 2.2 6.0 A 25-RF7P5-AL
5.0 4.0 10.5 B 25-RF014-BL
7.5 5.5 13.0 C 25-RF018-CL
10.0 7.5 17.0 C 25-RF018-CL
15.0 11.0 24.0 D 25-RF033-DL
20.0 15.0 30.0 D 25-RF033-DL
25.0 18.5 37.0 E 25-RF039-EL
30.0 22.0 43.0 E 25-RF039-EL
(1)
525...600V
50/60 Hz
3-Phase
0.5 0.4 0.9 A 25-RF8P0-BL
(2)
1.0 0.75 1.7 A 25-RF8P0-BL
(2)
2.0 1.5 3.0 A 25-RF8P0-BL
(2)
3.0 2.2 4.2 A 25-RF8P0-BL
(2)
5.0 4.0 6.6 B 25-RF8P0-BL
7.5 5.5 9.9 C 25-RF014-CL
10.0 7.5 12.0 C 25-RF014-CL
15.0 11.0 19.0 D 25-RF027-DL
20.0 15.0 22.0 D 25-RF027-DL
25.0 18.5 27.0 E 25-RF029-EL
30.0 22.0 32.0 E 25-RF029-EL
(1)
