PowerFlex 527 AC Drive Specifications
Output Ratings
Input Voltage Range Frame Size Catalog No.
Normal Duty Heavy Duty
Output Current (A)HP kW HP kW
100...120V AC (-15%, +10%) – 1-Phase Input, 0...230V 3-Phase Output
0.5 0.4 0.5 0.4 2.5 85...132 A 25-PM1-V2P5
1.0 0.75 1.0 0.75 4.8 85...132 B 25-PM1-V4P8
1.5 1.1 1.5 1.1 6.0 85...132 B 25-PM1-V6P0
200...240V AC (-15%, +10%) – 1-Phase Input, 0...230V 3-Phase Output
0.5 0.4 0.5 0.4 2.5 170...264 A 25-PM1-A2P5
1.0 0.75 1.0 0.75 4.8 170...264 A 25-PM1-A4P8
2.0 1.5 2.0 1.5 8.0 170...264 B 25-PM1-A8P0
3.0 2.2 3.0 2.2 11.0 170...264 B 25-PM1-A011
200...240V AC (-15%, +10%) – 1-Phase Input with EMC Filter, 0...230V 3-Phase Output
0.5 0.4 0.5 0.4 2.5 170...264 A 25-PM2-A2P5
1.0 0.75 1.0 0.75 4.8 170...264 A 25-PM2-A4P8
2.0 1.5 2.0 1.5 8.0 170...264 B 25-PM2-A8P0
3.0 2.2 3.0 2.2 11.0 170...264 B 25-PM2-A011
200...240V AC (-15%, +10%) – 3-Phase Input, 0...230V 3-Phase Output
0.5 0.4 0.5 0.4 2.5 170...264 A 25-PM1-B2P5
1.0 0.75 1.0 0.75 5.0 170...264 A 25-PM1-B5P0
2.0 1.5 2.0 1.5 8.0 170...264 A 25-PM1-B8P0
3.0 2.2 3.0 2.2 11.0 170...264 A 25-PM1-B011
5.0 4.0 5.0 4.0 17.5 170...264 B 25-PM1-B017
7.5 5.5 7.5 5.5 24.0 170...264 C 25-PM1-B024
10.0 7.5 10.0 7.5 32.2 170...264 D 25-PM1-B032
15.0 11.0 15.0 11.0 48.3 170...264 E 25-PM1-B048
20.0 15.0 15.0 11.0 62.1 170...264 E 25-PM1-B062
380...480V AC (-15%, +10%) – 3-Phase Input, 0...460V 3-Phase Output
0.5 0.4 0.5 0.4 1.4 323...528 A 25-PM1-D1P4
1.0 0.75 1.0 0.75 2.3 323...528 A 25-PM1-D2P3
2.0 1.5 2.0 1.5 4.0 323...528 A 25-PM1-D4P0
3.0 2.2 3.0 2.2 6.0 323...528 A 25-PM1-D6P0
5.0 4.0 5.0 4.0 10.5 323...528 B 25-PM1-D010
7.5 5.5 7.5 5.5 13.0 323...528 C 25-PM1-D013
10.0 7.5 10.0 7.5 17.0 323...528 C 25-PM1-D017
15.0 11.0 15.0 11.0 24.0 323...528 D 25-PM1-D024
20.0 15.0 15.0 11.0 30.0 323...528 D 25-PM1-D030
380...480V AC (-15%, +10%) – 3-Phase Input with EMC Filter, 0...460V 3-Phase Output
0.5 0.4 0.5 0.4 1.4 323...528 A 25-PM2-D1P4
1.0 0.75 1.0 0.75 2.3 323...528 A 25-PM2-D2P3
2.0 1.5 2.0 1.5 4.0 323...528 A 25-PM2-D4P0
3.0 2.2 3.0 2.2 6.0 323...528 A 25-PM2-D6P0
5.0 4.0 5.0 4.0 10.5 323...528 B 25-PM2-D010
7.5 5.5 7.5 5.5 13.0 323...528 C 25-PM2-D013
10.0 7.5 10.0 7.5 17.0 323...528 C 25-PM2-D017
15.0 11.0 15.0 11.0 24.0 323...528 D 25-PM2-D024
20.0 15.0 15.0 11.0 30.0 323...528 D 25-PM2-D030
25.0 18.5 20.0 15.0 37.0 323...528 E 25-PM2-D037
30.0 22.0 25.0 18.5 43.0 323...528 E 25-PM2-D043
525...600V AC (-15%, +10%) – 3-Phase Input, 0...575V 3-Phase Output
0.5 0.4 0.5 0.4 0.9 446...660 A 25-PM1-E0P9
