Allen-Bradley PowerFlex 70 Reference Manual

Start-Up 2-187
Figure 2.39 PowerFlex 70 & 700 Standard Control Option Startup (5)
StartUp
5. Speed Control
Enter value for
Speed Ref A Hi
60.0 Hz
xxx.x < yyy.y
StartUp
5. Speed Control
Enter value for
Speed Ref A Lo
0.0 Hz
xxx.x < yyy.y
StartUp
5. Speed Control
Enter choice for
Speed Control
<Analog Input>
Comm Adapter
Local HIM-Port 1
Remote HIM
Preset Speeds
MOP
Basic Start Up (Speed Control)
StartUp
5. Speed Control
This section
defines a source
from which to control
speed.
5-0
5-1
5-21
5-24
StartUp
5. Speed Control
Enter choice for
Signal Type
Voltage
Current
Enter
StartUp
5. Speed Control
Enter value for
Analog In 1 Hi
10.0 V
xxx.x < yyy.y
StartUp
5. Speed Control
Enter value for
Analog In 1 Lo
0.0 V
xxx.x < yyy.y
5-18
5-20
5-23
Go to 0-1 (6)
StartUp
5. Speed Control
Save MOP speed
at power down ?
<Yes>
No
PF70 StartUp
5. Speed Control
Enter value for
MOP Rate
5.0 Hz
xx.x < yy.y
Enter
5-15
5-17
Analog
Input 1
StartUp
5. Speed Control
Enter choice for
Input Signal
Analog Input 1
Analog Input 2
5-13
Analog Input
Enter
StartUp
5. Speed Control
Enter value for
Speed Ref A Hi
60.0 Hz
xxx.x < yyy.y
StartUp
5. Speed Control
Enter value for
Speed Ref A Lo
0.0 Hz
xxx.x < yyy.y
5-28
5-31
StartUp
5. Speed Control
Enter choice for
Signal Type
Voltage
Current
Enter
StartUp
5. Speed Control
Enter value for
Analog In 2 Hi
10.0 V
xxx.x < yyy.y
StartUp
5. Speed Control
Enter value for
Analog In 2 Lo
0.0 V
xxx.x < yyy.y
5-24
5-27
5-30
Enter
Analog
Input 2
StartUp
5. Speed Control
Enter choice for
Comm Adapter
Port 5-internal
Port 2-external
Port 3-external
5-2
StartUp
5. Speed Control
Enter choice for
Remote HIM
Port 2 (common)
Port 3
5-3
StartUp
5. Speed Control
Make a selection .
<Preset Speed 1>
Preset Speed 2
Preset Speed 3
Preset Speed 4
Preset Speed 5
Preset Speed 6
Preset Speed 7
Done
StartUp
5. Speed Control
Enter value for
Preset Speed 1
5.0 Hz
xxx.x < yyy.y
5-12
5-4
StartUp
5. Speed Control
Enter value for
Preset Speed 2
10.0 Hz
xxx.x < yyy.y
5-5
StartUp
5. Speed Control
Enter value for
Preset Speed 3
15.0 Hz
xxx.x < yyy.y
5-6
StartUp
5. Speed Control
Enter value for
Preset Speed 4
20.0 Hz
xxx.x < yyy.y
5-7
StartUp
5. Speed Control
Enter value for
Preset Speed 5
25.0 Hz
xxx.x < yyy.y
5-8
StartUp
5. Speed Control
Enter value for
Preset Speed 6
30.0 Hz
xxx.x < yyy.y
5-9
StartUp
5. Speed Control
Enter value for
Preset Speed 7
35.0 Hz
xxx.x < yyy.y
5-10
Remote
HIM
Preset
Speeds
Go to 0-1 (6)
StartUp
5. Speed Control
Digital Inputs
5 & 6 will be
set to MOP Inc &
MOP Dec.
5-14
StartUp
5. Speed Control
Save MOP speed
at stop ?
<Yes>
No
5-16
Enter
Enter
Enter
Done
Enter
Enter
Preset
Speed 1
Preset
Speed 2
Preset
Speed 3
Preset
Speed 4
Preset
Speed 5
Preset
Speed 6
Preset
Speed 7
Enter
Enter Enter
Enter
Go to 0-1 (6)
Local HIM-
Port 1
MOP
Enter/
Backup
StartUp
5. Speed Control
The next two
parameters link
a low speed
with a low
analog value.
5-22
StartUp
5. Speed Control
The next two
parameters link
a low speed
with a low
analog value.
5-29
EnterEnter
StartUp
5. Speed Control
The next two
parameters link
a high speed
with a high
analog value.
5-19
StartUp
5. Speed Control
The next two
parameters link
a high speed
with a high
analog value.
5-26
Enter Enter
Enter
StartUp
5. Speed Control
Note: Factory default
settings
provide preset
speed operation
from the digital
inputs, unless
you change
their function.
Enter
Enter
Adapter
5-11
5-25

Allen-Bradley PowerFlex 70 Specifications

General

Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Frequency Range	0 - 400 Hz
Humidity	5% to 95% non-condensing
Output Voltage	0 to Input Voltage
Control Methods	Sensorless Vector Control
Communications	Ethernet/IP, DeviceNet, ControlNet
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Ground Fault
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Enclosure Rating	IP20, NEMA Type 1
