Copy Cat 2-55
Table 2.H Recommended Filters
(1)
(1) Use of these filters assumes that the drive is mounted in an EMC enclosure.
Copy Cat Some PowerFlex drives have a feature called Copy Cat, which allows the
user to upload a complete set of parameters to the LCD HIM. This
information can then be used as backup or can be transferred to another
drive by downloading the memory.
Generally, the transfer process manages all conflicts. If a parameter from
HIM memory does not exist in the target drive, if the value stored is out of
range for the drive or the parameter cannot be downloaded because the drive
is running, the download will stop and a text message will be issued. The
user than has the option of completely stopping the download or continuing
after noting the discrepancy for the parameter that could not be downloaded.
These parameters can then be adjusted manually.
The LCD HIM will store a number of parameter sets (memory dependant)
and each individual set can be named for clarity.
Manufacturer Drive Type Frame
Manufacturer
Part Number
Class
Manufacturer
Part Number
Class
A
(Meters)
B
(Meters)
A
(Meters)
B
(Meters)
Deltron PowerFlex 70 A KMF306A 25 25 – – –
B w/o Filter KMF310A 50 25 – – –
B w/Filter KMF306A 100 50 MIF306 – 100
C KMF318A – 150 – – –
D KMF336A 150 5 MIF330 – 150
D w/o DC CM Capacitor KMF336A – 50 – – –
E – ––MIF3100–30
PowerFlex 700 0 KMF318A – 100 MIF316 – 150
1 KMF325A – 150 – – –
2 KMF350A 200 150 – – –
2 w/o DC CM Capacitor KMF350A 176 150 – – –
3 KMF370A 150 100 – – –
3 w/o DC CM Capacitor KMF370A 150 100 – – –
Schaffner PowerFlex 70 A FN3258-7-45 – 50 – – –
B w/o Filter FN3258-7-45 100 50 – – –
B w/Filter FN3258-7-45 – 100 – – –
C FN3258-16-45 – 150 – – –
D FN3258-30-47 0 0 FN258-30-07 – 150
D w/o DC CM Capacitor FN3258-30-47 – 150 – – –
PowerFlex 700 0 FN3258-16-45 – 150 – – –
1 FN3258-30-47 – 150 – – –
2 FN3258-42-47 50 50 – – –
2 w/o DC CM Capacitor FN3258-42-47 150 150 – – –
3 FN3258-75-52 100 100 – – –
3 w/o DC CM Capacitor FN3258-75-52 150 150 – – –
