Allen-Bradley PowerFlex 70 Reference Manual

2-54 CE Conformity
Table 2.E PowerFlex 70 – EN61800-3 EMC Compatibility
Table 2.F PowerFlex 70 – EN61800-3 First Environment Restricted Distribution
)
Table 2.G PowerFlex 700 EN61800-3 EMC Compatibility
(1)
(1) External filters for First Environment installations and increasing motor cable lengths in Second Environment
installations are available. Roxburgh models KMFA (RF3 for UL installations) and MIF or Schaffner FN3258
and FN258 models are recommended. Refer to Table 2.H
and http://www.deltron-emcon.com and http://
www.mtecorp.com (USA) or http://www.schaffner.com, respectively.
(2) Two turns of the blue comm option cable through a Ferrite Core (Frames A, B, C Fair-Rite #2643102002, Frame
D Fair-Rite #2643251002 or equivalent).
(3) Refer to the 1321 Reactor and Isolation Transformer Technical Data publication, 1321-TD001x for 1321-Mxxx
selection information.
Frame
Drive Description
Second Environment
Restrict Motor Cable
to 40 m (131 ft.)
Internal
Filter Option
External
Filter
(1)
Input
Ferrite
(2)
ADrive Only ✔ – ✔ –
Drive with any Comm Option ✔ – ✔ –
Drive with ControlNet ✔ – ✔✔
BDrive Only ✔✔––
Drive with any Comm Option ✔✔––
Drive with ControlNet ✔✔– ✔
CDrive Only ✔ –––
Drive with any Comm Option ✔ –––
Drive with ControlNet ✔ ––✔
DDrive Only ✔ –––
Drive with any Comm Option ✔ –––
Drive with ControlNet ✔ ––✔
EDrive Only ✔ –––
Drive with any Comm Option ✔ –––
Drive with ControlNet ✔ ––✔
Frame
Drive Description
First Environment Restricted Distribution
Restrict Motor
Cable to:
Internal
Filter Option
External
Filter
(1)
Comm Cable
Ferrite
(2)
Common
Mode Core
(3)
A Drive Only 40 m (131 ft.) – ✔ ––
Drive with any Comm Option 40 m (131 ft.) – ✔ ––
Drive with ControlNet 40 m (131 ft.) – ✔✔ –
B Drive Only 12 m (40 ft.) ✔ –– –
Drive with any Comm Option 12 m (40 ft.) ✔ –– –
Drive with ControlNet 12 m (40 ft.) ✔ – ✔ –
C Drive Only 12 m (40 ft.) – – – ✔
Drive with any Comm Option 12 m (40 ft.) – – – ✔
Drive with ControlNet 12 m (40 ft.) – – ✔✔
D Drive Only 12 m (40 ft.) – – – –
Drive with any Comm Option 12 m (40 ft.) – – – –
Drive with ControlNet 12 m (40 ft.) – – ✔ –
E Drive Only 30 m (98 ft.) – ✔ ––
Drive with any Comm Option 30 m (98 ft.) – ✔ ––
Drive with ControlNet 30 m (98 ft.) – ✔✔ –
Frame
Second Environment
Restrict Motor Cable to 30 m (98 ft.)
First Environment Restricted Distribution
Restrict Motor Cable to 150 m (492 ft.)
Any Drive and Option Any Drive and Option External Filter Required
0-6 ✔✔✔

Allen-Bradley PowerFlex 70 Specifications

General

Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Frequency Range	0 - 400 Hz
Humidity	5% to 95% non-condensing
Output Voltage	0 to Input Voltage
Control Methods	Sensorless Vector Control
Communications	Ethernet/IP, DeviceNet, ControlNet
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Ground Fault
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Enclosure Rating	IP20, NEMA Type 1
